ATEX Intrinsically Safe Type Approval
The IC-M87 ATEX and designated options are certifi ed to the ATEX Directive. It is suitable for use in hazardous areas where flammable gasses or liquids are used such as petroleum tankers and bulk cargo carrier. The approved rating is II2G Ex ib IIA T3 Gb.
IPX7, Waterproof Construction
The IC-M87 ATEX is built tough to withstand hazardous and unhospitable environments at sea and on land. Even if the IC-M87 ATEX is dropped into water, the IPX7 waterproof construction will protect it from harm (1 m depth for 30 minutes). The compact and durable body also has been tested to US. military specifications (MIL-STD 810).
Li-ion Battery for Extra Long Battery Life
With the standard 1950 mAh (typ.) rechargeable Li-ion battery pack, BP-227AX, the IC-M87 ATEX allows you up to 19 hours of operating time.* (Typical operation; Tx: Rx: Stand-by duty ratio=5:5:90)
22 Programmable Channels for PMR Use
The IC-M87 ATEX has 22 programmable channels for PMR use (146–174 MHz). Wide/narrow channel spacing is programmable for each channel, and CTCSS and DTCS signaling is built-in.
* Appropriate license will be required.
| Frequency Range | Marin [ Tx:156.000–161.450MHz Rx: 156.000–163.425MHz ] PMR [Tx/Rx:146.000-174.000 MHz] |
| Number of Channels | International marine channels + 22 programmable land channels |
| Operating Temperature Range | Marin [–15°C /+55°C ] PMR [ –25°C /+55°C ] PMR Atex [ –20°C /+55°C ] |
| Dimensions | 62×97×39mm |
| Weight | 280g (BP-227 ile) 290g (BP-227AX ile) |
| RF Output Power | 5/3/1W - ATEX versiyonu Marin 1/0.5W - PMR 1W |
| Receiver Sensitivity | Marin –2dBμ tipik / PMR –4dBμ tipik |
| Audio Output Power | Marin 0.2W / PMR 0.35W |
| Water & Dust Protection | IPX7 (Waterproof protection) |
| Durability Standard | MIL-STD 810F |
